Max power consumption: 90W Full system: up to 220W
Processor
Integrated NVIDIA Jetson AGX Orin 32GB (64GB) CPU: Up to 12-core ARM Cortex v8 GPU: NVIDIA Ampere architecture, up to 2048 CUDA cores + 64 Tensor cores Memory: Up to 64GB LPDDR5 Storage: Up to 4TB NVMe SSD Video Encoding: Up to 2× 4K60 Video Decoding: Up to 1× 8K30 HEVC
Operating System
Linux Ubuntu 20.04
Operating Temperature
-46°C ~ +65°C
Storage Temperature
-55°C ~ +85°C
Vibration
MIL-STD-810H Method 514.8, Procedure I (Category 20) Table C-V, Aircraft 2-minute test simulation: 4.0G, 40 minutes total Functional test: 4.2G, 60 minutes total Endurance test: 9.3G, 2.5 hours total
Shock
MIL-STD-810H Method 516.8, Procedure I (40G @ 11ms, ground shock) MIL-STD-810H Method 516.8, Procedure V (75G @ 6ms, ground shock)
Altitude
Up to 50,000ft (approx. 15,240m)
Humidity
95% Relative Humidity (RH), 60°C
IP
IP67
EMI Compliance
Compliant with MIL-STD-461G: CE101, CE102, CS101, RE102
KiteStrike II - ASO OperatorExterior: Black anodizing
Interior: Coated aluminum
Optical windows: 8.3mm diameter, 4x high-precision
Full system: up to 220W
CPU: Up to 12-core ARM Cortex v8
GPU: NVIDIA Ampere architecture, up to 2048 CUDA cores + 64 Tensor cores
Memory: Up to 64GB LPDDR5
Storage: Up to 4TB NVMe SSD
Video Encoding: Up to 2× 4K60
Video Decoding: Up to 1× 8K30 HEVC
Table C-V, Aircraft 2-minute test simulation: 4.0G, 40 minutes total
Functional test: 4.2G, 60 minutes total
Endurance test: 9.3G, 2.5 hours total
MIL-STD-810H Method 516.8, Procedure V (75G @ 6ms, ground shock)
